Assembly Instructions
‍

Sensors

Remove the sensors from their packaging.
Use the included Torx wrench to remove the white cover from the sensor to expose the sync ports.
Place the sensors on the included ball heads & stands, or other mounts.
‍

Cables — Data + Power Harnesses

Plug the power cable’s DC barrel connector into the sensor, and plug the USB Type-A connector into the included power supply. Plug the power supply into an AC power source.
Note: the included power supplies are for North American outlets, but will accept 110v-220v, so you can use a passive adapter to power the sensor in other regions.
Plug the SENSOR’s USB Type-C plug into the SENSOR, and the USB Type-A plug into the provided USB extender cable. Plug the other end of the extender cable into a suitable USB port of your capture computer.
‍

Cables — Sync

Remove the 3.5mm sync cables from the packaging.
Connect the cables from one sensor's Sync Out to the next sensor's Sync In. The first sensor in the chain will have nothing plugged into its Sync In port, and the last sensor will have nothing plugged into its Sync Out port.
‍

Cables — Everything Else

Remove the calibration chart from the packaging and mount it to a stand using the included clamp and ball head.
Make sure your capture volume has plenty of sensor-friendly light.

Follow our documentation to finalize your equipment setup, calibrate, and record.
